AISI 630 - 17-4 PH - Martensitic Stainless Steel - Stainless steel

AISI 630 - 17-4 PH

SAE 630 (17-4 PH, or 17-4; UNS S17400) is a martensitic precipitation-hardenable stainless steel comprised of 15-17.5% chromium, 3-5% nickel, and 3-5% copper, with 17% chromium and 4% nickel giving it its name.

Chemical Composition	0.07C-1Mn-0.04P-0.03S-1Si-15~17.5Cr-3~5Ni-3~5Cu-0.15~0.45Nb,Ta
Physical Property	• Density: 7.75 g/cm³ • Modulus of Elasticity: 196 GPa • Thermal Conductivity: 18.3 W/m.K • Specific Heat: 460 J/kg-°C • Melting Range: 1404 – 1440°C
Stock & Dimensions	Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs. • Bar: 0.5~600mm Diameter • Coil: 0.5~150mm Thick • Plate: 0.5~200mm Thick • Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick • Available in specific sizes
Product Forms	We provide you with a variety of product forms, including but not limited to: • Bar/Rod • Pipe/Tube • Coil/Strip • Plate/Sheet/Circle • Wire • Fitting (Flange, Elbow, Tee...) • Customize

Essential details

17-4PH can be heat treated to high levels of strength and hardness, and features corrosion resistance and machinability comparable to austenitic 304 stainless. Being martensitic, 17-4 is magnetic.

AISI 630 is capable of being hardened up to approximately 44 Rc when heat treated to condition H900.

Typical Applications:

- Aerospace

- Biomedical

- Chemical Processing

- Food Process Equipment

- Gate Valves

- Mechanical Components

- Nuclear Waste Processing and Storage

- Oil and Gas Production

- Pulp and Paper
