Nickel Alloy 200 is commercially pure wrought nickel grade (>99.0wt percent) and has a number of useful characteristics including good ductility and mechanical properties, permitting fabrications with sound welds to be constructed, particularly in the caustic concentration sector.

Products Description Company Profile

Overview

Commercially pure wrought Nickel with good mechanical properties over a wide range of temperature and excellent resistance to many corrosives, in particular hydroxides.

Good resistance to corrosion in acids and alkalis and is most useful under reducing conditions. Outstanding resistance to caustic alkalis up to and including the molten state. In acid, alkaline and neutral salt solutions the material shows good resistance, but in oxidizing salt solutions severe attack will occur. Resistant to all dry gases at room temperature and in dry chlorine and hydrogen chloride may be used in temperatures up to 550C. Resistance to mineral acids varies according to temperature and concentration and whether the solution is aerated or not. Corrosion resistance is better in de-aerated acid.

Applications

Manufacture and handling of sodium hydroxide, particularly at temperature above 300C.

Production of viscose rayon. Manufacture of soap.

Analine hydrochloride production and in the chlorination of aliphatic hydrocarbons such as benzene, methane and ethane.

Manufacture of vinyl chloride monomer.

Reactors and vessels in which fluorine is generated and reacted with hydrocarbons.

Chemical Requirements
Ni C Mn Cu S Si Fe
Max 0.15 0.35 0.25 0.01 0.35 0.40
Min 99.0
Mechanical Property Requirements
Ultimate Tensile Yield Strength (0.2% OS) Elong. R/A Hardness
Cold Worked
Min 75 KSi 50 KSi 15
Max
Min 515 MPa 345 MPa
Max
Hot Worked
Min 55 KSi 15 KSi 40
Max
Min 380 MPa 105 MPa
Max
Specifications
Form Standard
Metal Type UNS N02200
Bar ASTM B160 Din 17752 BS 3076
Wire
Sheet ASTM B162 Din 17750 BS 3072
Plate ASTM B162 Din 17750 BS 3072
Tube ASTM B622 ASTM B161 ASTM B163 Din 17740 BS 3074
Pipe ASTM B622 ASTM B161 Din 17740 BS 3074
Fitting ASTM B366
Forging ASTM B564
Weld Wire ERNi-CI
Weld Electrode ENi-1
NA 11 All forms
Din 2.4066 All forms
MACHINING DATA
Carbide tools are suggested
for rates better than 50% of Type 304.
Machining Type Suggested starting rates are:
Single Point turning : Roughing - 0.15" depth, 0.015"/rev feed -175 SFM
Finishing - 0.025" depth, 0.007"/rev feed - 200 SFM
Drilling : 1/4" Dia hole - 0.004"/rev feed - 60 SFM
1/2" Dia hole - 0.007"/rev feed - 60 SFM
3/4" Dia hole - 0.010"/rev feed - 60 SFM
Reaming : Feed - same as drilling - 100 SFM
Side and Slot Milling : Roughing - 0.25" depth - 0.007"/tooth feed - 125SFM
Finishing - 0.050" depth - 0.009"/tooth feed - 140SFM
These rates are for carbide tools,
Type C-2 for roughing, drilling and reaming.
Type C-3 for finishing.
